SMARTRUSS® CLASSIC
-
ADVANTAGES +
1. High tensile strength : 550 MPa yield strength
2. Structural load optimization : requires less building material, reduces overall structural and lifting costs
3. Corrosion-resistant coating technology
4. Conforms to AS/NZS 1365 : 1996 1 (tolerances for flat-rolled steel products)
5. Conforms to AS 1397 : 2001 (steel sheet and strip - Hot dipped Zinc-coated or Aluminium/Zinc-coated)
6. Certified with SNI 4096 : 2007 (BJ LAS G550 AS150)
7. Truecore steel coated with a 55% aluminium, 43.5% zinc, 1.5% silicon alloy coating which outperforms normal zinc galvanized steel by upto 4 times
8. AZ100 coating class (approximately 50 micrometer coating thickness) total both sides
-
ADVANTAGES COMPARE WITH GALVANIZED IRON +
1. Stronger protection
2. Superior cut edge protection
3. Better tight bend performance
-
ADVANTAGES COMPARE WITH MILD STEEL TRUSS +
1. Light and easy handling
2. Welding not required and screw fastened
3. Speed of construction
4. Does not require painting
5. Corrosion resistant
6. No material wastage
-
ADVANTAGES COMPARES WITH TIMBER +
1. Material consistency
2. Fire resistant
3. Unaffected by termites
4. Longevity
5. Less installation errors
6. Unaffected by warping
-
MEASUREMENT +
-
TECHNICAL DATA +
High tensile strength : 550 MPa yield strength
AZ100 coating class
ELASTICITY MODULUS = 2.1 x 105 MPA
SHEAR MODULUS = 8 x 104 MPA
-
WARRANTY +
1. BLUESCOPE ANTI RUST WARRANTY
2. BLUESCOPE STRUCTURAL WARRANTY
