SMARTDEK SUPERDYMA
-
COATINGS +
AZ-180 = 180 GR/M2 SUPERDYMA COATING
-
MEASUREMENT +
EFFECTIVE WIDTH = 960 MM
HEIGHT = 51 MM
RIB WIDTH = 122.5 MM
-
STRENGTH +
G-550 = YIELD STRENGTH 550 MPA
-
TECHNICAL DATA +
SECTION PROPERTIES SMARTDEK®
Base metal Tickness - BMT ( mm )
Unit
Symbol
0.70
1.00
1.20
Area
Mm²/m
A
889.69
1269.70
1523.96
Enertia Moment
Mm²/m
Ix"
409375.50
584791.00
701979.17
Section Modulus
Mm²/m
Zx"
16974
24357.17
29330.33
Mass
Kg/m2
7.38
10.34
12.33
-
THICKNESS +
STANDARD
0.70 BMT
NON STANDARD
1.00 BMT, 1.20 BMT
-
WEIGHT +
0.70 BMT = 7.38 KG/M2
1.00 BMT = 10.34 KG/M2
1.20 BMT = 12.33 KG/M2
-
ADVANTAGES +
1. Greater Durability,
· Excellent corrosion protection
2. Superior Performance
· Steel and concrete composite slabs are lighter and stronger than most conventional slabs
· Designed to prevent any longitudinal slip or transverse movement between the steel and concrete in the slabs itself
3. Economical
· Weight savings can be passed on to other areas of the design
· Steel decking acts as permanent formwork,saving both time and money
· Concrete displacement savings
4. Speedy, Safe Construction
· Composite slab effectively acts as a safe working platform
· Once slab is poured ,following trades can get on with their jobs almost immediately
· Work can continue unhindered on the floors above
5. Megafloor™ Software
· Powerful tool to design decking as formwork and composite
